পণ্যের বিবরণ:
|
Screen type: | 5.7 "TFT | Buttons control: | 14 membrane keys, service life ≥500 thousand times |
---|---|---|---|
Program space: | 1MB Flash + 8MB NorFlash | Memory space: | 128KB RAM + 8KB EEPROM + 1MB SRAM |
Installation method: | Outboard | Connection way: | A 34-pin AMP connector |
Brightness: | 525cd/㎡ | Shell material: | ABS+PC |
Protection grade: | Front IP65 | Processor: | 32-bit embedded microprocessor + FPGA |
লক্ষণীয় করা: | motor reduction gearbox,industrial programmable controller |
5.7 -inch XQ3102 color monitor
Technical parameters of XQ3102 | |||
Processor | 32-bit embedded microprocessor + FPGA, clock speed 120MHz | ||
Screen Type | 5.7" TFT | ||
Viewing angle | Left: 70 °, right: 70 °, up: 80 °, down: 80 ° | ||
Resolution | 640×480, 65536 color | ||
Brightness | 525cd/m2 | ||
Button control | 14 membrane keys, service life ≥500 thousand times | ||
Program space | 1MB Flash + 8MB NorFlash | ||
Memory space | 128KB RAM + 8KB EEPROM + 1MB SRAM | ||
Calendar Clock | Yes | ||
Built-in buzzer | Yes | ||
Connection | A 34-pin AMP connector | ||
Working temperature | -30~+70℃ | ||
Storage temperature | -35~+80℃ | ||
Relative humidity | 20%~96% RH | ||
Atmospheric pressure | 86~106 KPa | ||
Shell material | ABS+PC | ||
Installation | Outboard | ||
Electrical parameters | |||
Supply voltage | DC12V / DC24V, range DC9V ~ DC36V, reverse polarity protection | ||
Power consumption | ≤6W | ||
Communication Interface |
Line 2 CAN: compliance with ISO 11898 standard, the baud rate: 50Kbit / s ~ 1Mbit / s (the default value 250Kbit/s); Line 1 RS422: standard RS422 communication baud rate 4.8/9.6/ 19.2Kbit/s, etc. (default 9.6Kbit/s) |
||
Video input | Line 2 | ||
CVBS signal formats PAL or NTSC, connected with 75Ω impedance | |||
Environment test | |||
Degree of protection | Front IP65 | ||
Anti-vibration characteristics | GB/T 2423.10 | ||
Impact properties | GB/T 2423.5 | ||
Surge Immunity | GB/T 17626.5 | ||
Electrical fast transient burst immunity | GB/T 17626.4 | ||
Electrostatic discharge immunity | GB/T 17626.2 | ||
RF electromagnetic field radiation immunity | GB/T 17626.3 | ||
RF induced conduction harassment immunity | GB/T 17626.6 |
XQ3102 color display adopts 32-bit embedded microprocessor and FPGA as the central processing unit, high efficiency. With state monitoring, alarm message alert system diagnostics.
Wide supply voltage range, low-power, reverse polarity protection, comes with a buzzer alarm, configure CAN, RS422 communication interface, easy system integration, system expansion, providing an open, programmable platform, personalized designed by the user.
To provide customers with technical advice, help the user to choose the right andgood product.
1.Responsible for product quality, and carry out "three-item of warranty".
2.The warranty period of our product is a year or 2000 hours .
3.Aftersales service reply will be in a timely manner, timely processing.
